RACO
High performance
Electric actuator T1T4 - 148416
| Adjustment range | 100 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 |
| a3 (mm) | 455 | 555 | 655 | 755 | 855 | 955 | 1155 | 1355 |
| Spindle type | Trapezoidal screw |
| Thrust force (kN) | 5.00 |
| Voltage (V) | 400 |
| Frequency (Hz) | — |
| Speed (mm/s) | 1.50 - 15.00 |
| Power (kW) | 0.37 |
| Current (A) | 1.60 |
| Converter (kW) | 1.10 |
